ADT-CNC4620 Two Axis Turning /Lathe CNC Controller

This Two Axis Turning /Lathe CNC Controller is the updated version ,adopting an ARM9 high performance CPU and super-large programmable FPGA, real-time multi-task control technology and hardware interpolation technology.

£690.00

Prices are NOT inclusive of VAT

  • 7.0 Inch color display, two axis
  • ARM 9 CPU+FPGA
  • Tool nose radius compensation
  • Ethernet network interface
  • Support B macro function
  • U flash and USB communication
  • PLC function
  • Mutil-language library function.

Option Spare Parts

Handheld box CNC4a

 Additional Panel FCN C4M

  • 7.0 inch color display screen
  • it is new upgraded version base on CNC4220 two axis CNC lathe system .
  • adopt ARM9 high performance CPU
  • super-large programmable FPGA.
  • real-time multi-task control technology and hardware interpolation technology
  • According to different demand of customer, it can be suitable to match stepping and servo driver,and realize high performance ratio
  • with USB ,Flash and RS232 COM communication etc,. lots of kinds communication mode, it can easy realize the different data transmission and update software.
  • With network interface, the system support remote monitoring and transmission processing of DNC file
  • Open CNC platform, capable of custom-tailoring private system according to the specific requirements;
  • With complete self-diagnostic function, internal and external real-time display, it will show alarming if any exceptional.
  • Support additional panel and external handheld box operation , it is convenient to cutter aligner for customer.
  • Macro-variable , programming of macro definition, enable to lots of kind of logical relation, support macro programming with parameter to being used, it is more convenient to user.
  • DXF+G code template function, switching the DXF file to G code for processing automatically
