ADT-HC4500 is a new style Plasma/Flame cutting controller based on the HC4300. It adopts an ARM9 processor, super large customized IC chip, 7 Inch color LCD display screen, high Speed /precision and stable quality of hardware.


Prices are NOT inclusive of VAT

  • ARM9 high-speed Microprocessor and super large programmable FPGA
  • Real time multitask control technology and hardware interpolation technology
  • 7 Inch real color display screen, Friendly and easily operation interface,
  • Supporting multi language display;
  • All Photovoltaic isolation control, super large anti-interface ability;
  • Large storage space process file: 256M, demand complicated/large program running and processing
  • Plasma /flame controller can control 3 step/servo motor at the same time, which adopt doubt axis at one time or develop 3 axis according customer requests;
  • Graphic library: 63 graphs, which can cutting hole or slice as choose;
  • Graphic Dealing function, which are supporting edit Radom rotation, correction and mirror image function etc;
  • Delay, preheating, perforating, changing nozzle, moving parts, moving parts etc process control;
  • Break point recovery function
  • USB, RS232 serial communication control, directly read file buy U disk
  • Customized software: strong>it can apply for Plasma, Punch and engraving function within one machine, simple laser cutting etc.

Controller + Data Line + Connector

Optional Parts:
Nesting Software+ 24V power

Power Request

DC 24V 50/60Hz

Power Dissipation


Work Temperature


Storage Temperature


Work Humidity


Storage Humidity


Digital Input:
  • Channel: 32, All Photovoltaic isolation
  • Input Voltage: 12-24V DC
  • High Level >4.5V
  • Low Level <1.0V
  • Isolation Voltage: 2500V DC
  • Counting Input:
  • Channel: Spindle ABZphase coding input, All Photovoltaic isolation
  • Maximum counting frequency: 2MHz
  • Input Voltage: 5-24V DC
  • High Level>4.5V
  • Low Level<1.0V
  • Isolation voltage: 2500V DC
Pulse output:
  • Channel: 3 Axis Pulse, 3 axis direction, All photovoltaicisolation
  • Maximum pulse frequency: 2MHz
  • Output type: 5Vdifferential output
  • Output mode: Pulse +direction or pulse + pulse
Digital Output:
  • Output Channel: 16, All photovoltaic isolation
  • Output type: NPN open-collectorout put 12-24V DC, Max current 100mA.
  • RS-232 Baud rate(bps):
  • 1200,2400,4800,9600,19200,38400,57600,115200


  • CNC plasma/Flame cutting machine
  • Laser cutting machine
  • Plasma, punch, engraving all in one machine.
